Technical Specifications for MS Plates
| Size in Feet |
Width in mm |
Length in mm |
Thickness in mm |
Weight per PC in kg |
| 8'x4' |
1220 |
2440 |
0.8 |
18.769 |
| 8'x4' |
1220 |
2440 |
1 |
23.234 |
| 8'x4' |
1220 |
2440 |
1.2 |
28.1 |
| 8'x4' |
1220 |
2440 |
1.5 |
35.01 |
| 8'x4' |
1220 |
2440 |
2 |
46 |
| 8'x4' |
1220 |
2440 |
2.5 |
60 |
| 8'x4' |
1220 |
2440 |
2.8 |
65.5 |
| 8'x4' |
1220 |
2440 |
4 |
95.25 |
| 8'x4' |
1220 |
2440 |
6 |
142.88 |
| 8'x4' |
1220 |
2440 |
8 |
190.59 |
| 8'x4' |
1220 |
2440 |
10 |
238.14 |
| 8'x4' |
1220 |
2440 |
12 |
185.76 |
| 8'x4' |
1220 |
2440 |
15 |
375 |
| 8'x4' |
1220 |
2440 |
20 |
476 |
| 8'x4' |
1220 |
2440 |
25 |
585 |
|
MS Plates conform to international quality parameters
ST 37.2 as per DIN Spec 171000 and JIS 3193 & 3131
MS Plates between 0.8 to 2.8mm can be supplied in customer specified length.
Applications for Mild Steel Plates
Billboard faces, fuel tanks, water tanks/reservoirs, furniture
trucks/bus bodies, wheel barrows, doors and many more.
Louvers
From Mild steel plates, Roofings can offer extra accessories such as louvers- which can be used in windows,gates, garage doors in these sizes:
- 1.22m x 75mm x 1.0mm
- 1.22m x 75mm x 1.2mm
- 1.22m x 75mm x 1.5mm
|
